Description
This Electronic Monitoring Unit ( EMU ) is for the transmission of the SCBA cylinder pressure converted into a wireless signal. And this signal can be sent to the HUD or sent to the Personal Distress Alarm Unit so the user can know the status of cylinder pressure constantly.
Application
The Electronic Monitoring Unit ( EMU ) using high-precision sensors, low-power radio transmitter chip, large-capacity battery, you can ensure that under normal use, continuous work for more than a year, using waterproof seal design ensures that moisture in the field with water under reliable work environment.
Features
• Consistent with public safety industry standard positive pressure firefighting air respirator GA 124-2013.
• Intrinsically Safe Certification ExiaⅡCT3Ga.
• Using a large capacity battery, ensure long working hours (one year) does not need to replace the battery.
• HUD wireless connection.
• After pairing is good, when you use without action.
• Low-power, long-distance wireless module.
• Waterproof design.
• Wireless communication distance> 1.5 m.
Electronic Monitoring Unit parameters
|
Technical Parameters
|
Model No: BAEMU60®
|
|
Operating Voltage: 3.6V
|
|
Protection class: IP67
|
|
Accuracy class: 1.0class(±0.3M)
|
|
Detect pressure range: 0~40MPa
|
|
Wireless communication distance: ≥1.5M
|
|
Operating Temperature: -20℃～60℃
|
|
Explosion levels: ExiaⅡCT3 Ga (intrinsically safe)
|
|
Relative humidity: Working10% ～ 94%RH；Storage：20%～80%RH
|
|
Outer dimensions: 88*55*32mm
|
|
OEM service: logo and pattern customization
|
|
Packing: one intactly packaged, 5 sets into one carton
|
